• Select Drive 2-speed transfer case
• 3.73 axle ratio
• Four wheel drive
• Automatic locking front hubs (electric shift)
• 58 amp-hour (540 CCA) maintenance-free battery
• 95 amp alternator
• 6' pickup box
• Fuel tank/transfer case skid plate
• (2) front tow hooks
• (1) rear tow hook
• 4940# GVWR/1260# maximum payload
• Short/long arm front suspension
• Front/rear stabilizer bar
• HD gas shock absorbers
• P215/75R15SL all-terrain SBR OWL tires
• Full size spare tire
• (5) 15" argent wheels w/bright hub caps
• Pwr rack & pinion steering
• Pwr brakes
• Rear-wheel anti-lock brake system
• 19.5 gallon fuel tank
• Jack & tools
• Plastic-head single-key ignition/door lock system

• Painted front bumper
• Painted rear step bumper w/safety chain holes
• Wheel-lip moldings
• Painted grille
• Tri-color tail lights
• Dual black mirrors
• Solar tinted glass
• Speed-sensitive intermittent windshield wipers
• Black door handles
• Quick-release tailgate w/black handle
• Platinum front/rear mud flaps

• 60/40 cloth split bench seat
• Rear jump seats
• Black vinyl floor covering w/insulation
• Floor consolette w/single cupholder
• Black scuff plates
• Black steering wheel
• Tachometer
• Inside hood release
• Electronic AM/FM stereo radio w/digital clock, (2) speakers
• Color-keyed full-width instrument panel pad-inc: side window demisters, air registers, color-keyed applique
• 12 volt pwr point
• Soft-release parking brake
• Warning chimes-inc: headlights-on, key-in-ignition, seat belt
• Color-keyed glove box/ash tray
• Cigarette lighter
• Color-keyed interior A/B-pillar moldings
• Day/night interior rearview mirror
• Color-keyed plastic door trim panels w/padded armrest & black door handles
• Color-keyed headliner
• Color-keyed vinyl sun visors w/pockets
• Color-keyed rear-of-cab coat hook
• Dual door-operated front dome light

• Driver/passenger air bag w/manual passenger-side deactivation
• Rear-wheel anti-lock brake system
• Adjustable height front shoulder safety belts w/top release
• Single-note horn

3.0L (182) SEFI V6 ENGINE

• (STD)

• Optional Payload Package #1
• 60/40 Split Cloth Bench Seat
• Argent Wheels w/Bright Hub Caps
• 3.73 Axle Ratio
• 4 Speakers
• Front Center Armrest w/Storage
• Front beverage holders
• Variably intermittent wipers
• Split folding rear seat
• Rear step bumper
• Rear anti-roll bar
• Power steering
• Passenger cancellable airbag
• Illuminated entry
• Front wheel independent suspension
• Front anti-roll bar
• Dual front impact airbags
• AM/FM radio
• ABS brakes
• Voltmeter
• Tachometer

• Mileage
• EPA Fuel Economy Est - City (MPG): 17
• EPA Fuel Economy Est - Hwy (MPG): 22
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 540
• Maximum Alternator Capacity (amps): 95
• Maximum Alternator Watts: 1425
• Cooling System
• Total Cooling System Capacity (qts): 7.2
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 2710
• Gross Axle Wt Rating - Rear (lbs): 2600
• Curb Weight - Front (lbs): 2128
• Curb Weight - Rear (lbs): 1469
• Gross Vehicle Weight Rating Cap (lbs): 4940
• Gross Combined Wt Rating (lbs): 6000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 2000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 200
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 2000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 300
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): N/A
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): N/A
• Suspension
• Suspension Type - Front: Coil Spring
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 2510
• Spring Capacity - Rear (lbs): 2600
• Axle Type - Front: Short/Long Arm
• Axle Type - Rear: Ford Semi-Floating
• Axle Capacity - Front (lbs): 2850
• Axle Capacity - Rear (lbs): 2750
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 1.19
• Shock Absorber Diameter - Rear (mm): 1.19
• Stabilizer Bar Diameter - Front (in): 1.14
• Stabilizer Bar Diameter - Rear (in): 0.63
• Brakes
• Brake Type: Power
• Brake ABS System: Rear Wheel
• Disc - Front (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 11.28 x 1.02
• Drum - Rear (Yes or ): Yes
• Rear Drum Diam x Width (in): 10.00 x 2.50
• Tires
• Front Tire Order Code: T7F
• Rear Tire Order Code: T7F
• Front Tire Size: P215/75R15SL
• Rear Tire Size: P215/75R15SL
• Spare Tire Size: P215/75R15SL
• Front Tire Capacity (lbs): 1583
• Rear Tire Capacity (lbs): 1583
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: 750
• Revolutions/Mile @ 45 mph - Rear: 750
• Revolutions/Mile @ 45 mph - Spare: 750
• Wheels
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr Rack & Pinion
• Steering Ratio (:1), On Center: 18.7
• Turning Diameter - Curb to Curb (ft): 43.0
• Turning Diameter - Wall to Wall (ft): 45.2
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 19.5
• Fuel Tank Location: Midship
• Exterior Dimensions
• Wheelbase (in): 125.9
• Length, Overall w/o rear bumper (in): 202.9
• Width, Max w/o mirrors (in): 69.4
• Height, Overall (in): 64.9
• Overhang, Front (in): 33.3
• Overhang, Rear w/o bumper (in): 42.5
• Front Bumper to Back of Cab (in): 121.3
• Cab to Axle (in): 37.7
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): - TBD -
• Frame Width, Rear (in): 32.8
• Ground Clearance, Rear (in): 7.4
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 71.8
• Cargo Box Width @ Top, Rear (in): - TBD -
• Cargo Box Width @ Floor (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): 40.4
• Cargo Box (Area) Height (in): 16.5
• Tailgate Width (in): 52.0
• Cargo Volume (ft³): 37.4
• Ext'd Cab Cargo Volume (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 39.2
• Front Leg Room (in): 42.2
• Front Shoulder Room (in): 53.8
• Front Hip Room (in): 52.7
• Second Head Room (in): 35.6
• Second Leg Room (in): 40.3
• Second Shoulder Room (in): 15.3
• Second Hip Room (in): 19.8
• Summary
• Vehicle Name: Ford Ranger
• Body Style: Supercab 6'
• Body Code: 125.9" WB
